IEC 60870-5-104 Windows SDK

FreyrSCADA IEC 60870-5-104 Demo Win DLL includes simple (Server & Client C programs )example using a Command window and command line inputs.

The source code will allow you to quickly compile your own examples with the features of your existing development environment to work with our IEC 60870-5-104 DLL.

FreyrSCADA IEC 60870-5-104 Windows SDK contains Win DLL (precompiled library), Static link lib, Demo IEC104 Server & Client programs, Visual Studio Demo console project files, Doxygen .

We used Visual studio compiler to create the dll, sample test projects.

Supported Information Types


Process information in monitoring direction :



1 Single point information M_SP_NA_1
2 Single point information with time tag M_SP_TA_1
3 Double point information M_DP_NA_1
4 Double point information with time tag M_DP_TA_1
5 Step position information M_ST_NA_1
6 Step position information with time tag M_ST_TA_1
7 Bit string of 32 bit M_BO_NA_1
8 Bit string of 32 bit with time tag M_BO_TA_1
9 Measured value, normalized value M_ME_NA_1
10 Measured value, normalized value with time tag M_ME_TA_1
11 Measured value, scaled value M_ME_NB_1
12 Measured value, scaled value with time tag M_ME_TB_1
13 Measured value, short floating point value M_ME_NC_1
14 Measured value, short floating point value with time tag M_ME_TC_1
15 Integrated totals M_IT_NA_1
16 Integrated totals with time tag M_IT_TA_1
17 Event of protection equipment with time tag M_EP_TA_1
18 Packed start events of protection equipment with time tag M_EP_TB_1
19 Packed output circuit information of protection equipment with time tag M_EP_TC_1
20 Packed single-point information with status change detection M_PS_NA_1
21 Measured value, normalized value without quality descriptor M_ME_ND_1



Process telegrams with long time tag ( 7 octets ) :



30 Single point information with time tag CP56Time2a M_SP_TB_1
31 Double point information with time tag CP56Time2a M_DP_TB_1
32 Step position information with time tag CP56Time2a M_ST_TB_1
33 Bit string of 32 bit with time tag CP56Time2a M_BO_TB_1
34 Measured value, normalized value with time tag CP56Time2a M_ME_TD_1
35 Measured value, scaled value with time tag CP56Time2a M_ME_TE_1
36 Measured value, short floating point value with time tag CP56Time2a M_ME_TF_1
37 Integrated totals with time tag CP56Time2a M_IT_TB_1
38 Event of protection equipment with time tag CP56Time2a M_EP_TD_1
39 Packed start events of protection equipment with time tag CP56time2a M_EP_TE_1
40 Packed output circuit information of protection equipment with time tag CP56Time2a M_EP_TF_1



Process information in control direction :



45 Single command C_SC_NA_1
46 Double command C_DC_NA_1
47 Regulating step command C_RC_NA_1
48 Setpoint command, normalized value C_SE_NA_1
49 Setpoint command, scaled value C_SE_NB_1
50 Setpoint command, short floating point value C_SE_NC_1
51 Bit string  32 bit C_BO_NA_1



Command telegrams with long time tag ( 7 octets ) :



58 Single command with time tag CP56Time2a C_SC_TA_1
59 Double command with time tag CP56Time2a C_DC_TA_1
60 Regulating step command with time tag CP56Time2a C_RC_TA_1
61 Setpoint command, normalized value with time tag CP56Time2a C_SE_TA_1
62 Setpoint command, scaled value with time tag CP56Time2a C_SE_TB_1
63 Setpoint command, short floating point value with time tag CP56Time2a C_SE_TC_1
64 Bit string 32 bit with time tag CP56Time2a C_BO_TA_1



System information  in monitoring direction :



70 End of initialization M_EI_NA_1



System information in control direction :



100 (General-) Interrogation command C_IC_NA_1
101 Counter interrogation command C_CI_NA_1
102 Read command C_RD_NA_1
103 Clock synchronization command C_CS_NA_1
104 ( IEC 101 ) Test command C_TS_NB_1
105 Reset process command C_RP_NC_1
106 ( IEC 101 ) Delay acquisition command C_CD_NA_1
107 Test command with time tag CP56Time2a C_TS_TA_1



Parameter in control direction :



110 Parameter of measured value, normalized value P_ME_NA_1
111 Parameter of measured value, scaled value P_ME_NB_1
112 Parameter of measured value, short floating point value P_ME_NC_1
113 Parameter activation P_AC_NA_1



File transfer :



120 File ready F_FR_NA_1
121 Section ready F_SR_NA_1
122 Call directory, select file, call file, call section F_SC_NA_1
123 Last section, last segment F_LS_NA_1
124 Ack file, Ack section F_AF_NA_1
125 Segment F_SG_NA_1
126 Directory F_DR_TA_1
127 QueryLog – Request archive file F_SC_NB_1



Protocol Features

  • Application Layer
    On-demand transmission (e. g. single indications, analogs...)
    Spontaneous transmission (e. g. single indications with time tag ...)
    Direct command transmission (with select before operate)
    Clock synchronization
    File Transfer
  • Address Space
    Common Address of ASDU: 1..65535
    Information object address: 1..16777215


Application Examples
  •     Integrate existing devices to a modern control system with a field proven product
  •     Use the IEC-104 event based communication instead of polling
  •     Feeder automation
  •     Substation automation
  •     Utility automation
  •     Reclosers
  •     Protection relays




  • Royalty-free Readily deployable IEC 104 Server and Client Stack on royalty-free basis
  • Developed in C language and can be ported to any Microcontroller platform
  • Enables faster firmware development of IEC 60870-5-104 enabled field devices
  • Supports all the major ASDU(Monitor, Control, Parameter, File Transfer)



This evaluation package allows you to:

  • Access product manual(API documentation)(pdf, Doxygen html)
  • Browse the IEC 60870-5-104 library API documentation
  • Study the source code of the IEC 60870-5-104 examples provided
  • Modify and compile the IEC 60870-5-104 examples
  • Create your own IEC 60870-5-104 programs and test with leading test tools like (ASE,...)
  • You can use the source code of the application examples and modify them according to your needs.

Minimum system requirements:

  • Windows XP, Vista, Windows 7, 8 and 10
  • Visual studio / Any IDE supports C & C++ Programming

You can also try our IEC 60870-5-104 Server Simulator, Client Simulator and IEC 60870-5-104 Linux SDK


Download Evaluation Kit - IEC 60870-5-104 Development Bundle

New updated Version of IEC 60870-5-104 Simulator & SDK (Software Development Kit) is available now.
FreyrSCADA IEC-60870-5-104 Development Bundle v21.04.002
In the Development Bundle, We included IEC 60870-5-104 Server & Client Simulator, Windows & Linux SDK.
